Equipment Engineered for Excellence
Available Equipment: Batch Processing
150 CF Double Cone Formularor
Vessel: Jacketed 316 Stainless Steel
Maximum Product Density: 65lb/ft3
Maximum Load Capacity: 10,000 lbs. (Based on Max Product Density)
Loading: GEMCOMATIC or VAC-U-MAX Vacuum Loader from Bags & Bulk Bags
Unloading: GEMCOMATIC or VAC-U-MAX Bulk Bag Station
Heating: Self Contained - Hot Oil
Automation: Full PLC control with Recepies
50 CF Double Cone Formulator
Vessel: Jacketed 316 Stainless Steel
Maximum Product Density: 65lb/ft3
Maximum Load Capacity: 3,500 lbs. (Based on Max Product Density)
Loading: GEMCOMATIC or VAC-U-MAX Vacuum Loader from Bags & Bulk Bags
Unloading: GEMCOMATIC or VAC-U-MAX Bulk Bag Station
Heating: Self Contained - Hot Oil
Automation: Full PLC control with Recepies
30 CF Double Cone Formulator
Vessel: Jacketed 316 Stainless Steel
Maximum Product Density: 65lb/ft3
Maximum Load Capacity: 2.150 lbs. (Based on Max Product Density)
Loading: GEMCOMATIC
Unloading: GEMCOMATIC or Bulk Bag Station
Solvent Recovery: Self Contained 316 Stainless to Full Vacuum
Heating: Self Contained - Hot Oil
Automation: Full PLC control with Recipes
Semi-Continuous Processing - 30 CF Double Cone Formulator
Vessel: Jacketed 316 Stainless Steel
Maximum Product Density: 65lb/ft3
Maximum Load Capacity: 2.600 lbs. (Based on Max. Product Density)
Loading: Manual
Unloading: Drums or Bulk Bag Station
Automation: Full PLC control with recipes
Available Equipment - APS Lab
Beckman Coulter LS I3 320 Laser Defraction Particle Size Analyizer for both Liquid and Dry Modules
GEMCO ½ -150 CF (4250 Liter) Working Capacity Formulators
Ohaus MB-45 Moisture Balance
Bucci R124 Rotovap
Ovens
Balances
Screeners
* Additional equipment available.
APS is exclusively equipped with different sized GEMCO Formulators to provide customers with the capabilities of one-stop processing. We provide 1/2, 3, 50, 50, and 150 CF working capacity units. All of these are completely scalable!
GEMCO formulators are able to blend, dry and apply surface treatments to many types of materials. These often come from the chemical, pharmaceutical, food, nutraceuticals, vitamin, cosmetics, plastics, electronics, and precious metals industries.
APS can process material under high vacuum and inert atmospheres when hazardous, oxidative, or heat sensitive materials are used. Solvents can be recovered and, in many cases, reused. This eliminates hazardous waste build up from continued processing. Since the formulators are completely enclosed systems able to handle hazardous, flammable, and volatile material, the risk to the environment and to operator health is eliminated.
All our formulators are equipped with an intensifier bar. This bar helps de-agglomerate the particles being blended or dried. It also allows smaller quantities of actives with targets as low as .1% to disperse evenly throughout a blend. Integrated liquid feed through the bar or interchangeable nozzles, provided on all Formulators, allows us to spray in binders or coatings and then simultaneously dry and size the product.
Equipment Engineered for Excellence
From development and optimization to scale up, Advanced Powder Solutions experts take you through a step-by-step process with our tested and proven guides. We address all processing logistic issues so you can focus on running your business.
There is no more guess work on production times and capacities. Our formulas combined with experience will provide you with the most accurate scale-up estimates available.
Customers are able to use Advanced Powder Solutions as their very own scale-up test facility. We provide adequate batch sizes to run processing tests and analyses.
PRODUCTION RUNS UP TO 10,000 POUNDS
Watch your production costs drop dramatically as you see batch turnaround time decrease. Advanced Powder Solutions becomes your Extension to Manufacturing. Begin by filling out the following downloadable forms and submitting to our office here.
